Image Device: 1/2.9\" CMOS SONY Exmor IMX323LQN

DSP: Nextchip NVP2441

Resolution: 2.0 Mega Pixels

Effective Pixels: 1920(H) × 1080(V)

Image System: PAL, NTSC

Synchronization: Internal

S/N: More than 50dB (AGC off)

Mini. Illumination: Low 0.01LUX/F1.2 (AGC ON)

Video Output: 4 in 1: AHD, TVI, CVI, CVBS output Selectable by OSD.

Menu

OSD Menu: OSD Cable optional, UTC Coaxial Control (via DVR) support

BLC: OFF, HSBLC, BLC

AGC: 0→15 Adjustable

White Balance: ATW, AWC-SET, Indoor, Outdoor, Manual, AWB

Brightness: 0→100 Adjustable

Shutter: Auto, 1/25→1/50000, FLK, X2→X30

Sharpness: Auto(0→10), Off

DEFOG: OFF, AUTO

D-WDR: ON(1→8), OFF, Auto

Mirror: OFF, Mirror, V-Flip, Rotate

Day & Night: EXT, B/W, COLOR, AUTO

3D/2D-DNR: OFF, LOW, MIDDLE, HIGH

SENSE-UP: Auto(X2→X30), OFF

Camera Title: Off, On

Motion: OFF, ON(4 AREAS)

Privacy: OFF, ON(4 AREAS)

Defect: DPC (Off, On)

Monitor: CRT, LCD

LSC: Off, On

Language: Multi Languages

Feature

Max. IR LED Length: 2pcs Array IR LED, 25M, Smart IR

Focal Length Lens: 3.6mm Mega Pixel fixed Lens

Mount Type Lens: M12

General

Power Supply: DC12V ±10%

Working Environment: -20℃～+50℃, Humidity 95% (No condensation)

External Protection: IP66 Grade (waterproof IP66)

Power Consumption: 160mA , Max 420mA ( IR on)

Transmission Distance: Over 500m via 75±3Ω Coaxial cable

Ingress Protection: Metal Dome
