- Red LED with current limiting resistor.
- Three different resistance selectable (270, 470, 680 ohm).
- Choice of red, yellow, blue or green finish also available for custom-made.
- Clear protection cover is also available (optional).
Operating Contact |
6A 125/250VAC |
Resistance |
30MΩ |
Ambient Temperature |
-25oC ~ +85oC |
Dimensions (mm) H x W x D |
87.5 x 87.5 x 54 |
Weight |
About 145g |
